VITools: The Virtual Imaging Trial Orchestrator¶
VITools is an orchestration package for conducting Virtual Imaging Trials (VCTs). It serves as a generic, horizontal adaptor layer connecting common imaging simulation backends with diverse digital phantoms.
By abstracting away the unique complexities of individual simulation packages, VITools allows researchers to focus on the study design rather than the underlying mechanics of the simulator.
VITools vs. VICTRE¶
It is important to distinguish VITools from VICTRE (Virtual Imaging Clinical Trial for Regulatory Evaluation):
VICTRE is a vertical stack: It is a specific, end-to-end pipeline designed for a specific purpose (mammography/tomosynthesis breast imaging). It tightly couples specific phantom models, compression simulations, and MC-GPU imaging.
VITools is a horizontal adaptor layer: It is a general-purpose infrastructure designed to run any compatible simulation backend with any compatible phantom. While VICTRE represents a specific application, VITools represents the “operating system” or framework upon which many such applications (including future versions of VICTRE-like pipelines) can be built.
Key Features¶
Object-Oriented Interface: Simplifies complex simulations with intuitive Phantom, Scanner, and Study classes.
Extensible by Design: Easily add new phantoms via a pluggy-based plugin system.
Automated Workflow: Handles the end-to-end process from phantom definition to DICOM image generation.
Scalable Studies: The Study class enables the management and execution of large-scale experiments, with support for parallel execution on SGE clusters.
Configuration-Based: Leverages the powerful configuration system of the underlying backend (e.g., XCIST) for detailed control.
How it Works¶
VITools standardizes the VCT workflow into two primary wrapping steps:
Wrap your Imaging Simulator: The Scanner class wraps a simulation engine (backend), exposing a common API for configuring physics, geometry, and protocols.
Wrap your Phantom: The Phantom class wraps your digital subject data (numpy arrays, voxel spacing), making it intelligible to the scanner wrapper.
Once these two components are wrapped, VITools handles the “handshake” between them—voxelizing the phantom, generating configuration files, running the simulation, and reconstructing the output—allowing you to run large, complex studies with minimal boilerplate.
Supported Backends & Roadmap¶
VITools is designed to be backend-agnostic.
Current Support:
XCIST (The X-ray CT Image Simulation Toolkit): The default backend for VITools.
Open Source: XCIST is available under the BSD 3-Clause License.
Validated: XCIST is a thoroughly validated 3D CT simulation framework.
Wu et al., “XCIST—an open access x-ray/CT simulation toolkit,” Physics in Medicine & Biology, 2022.
Zhang et al., “Development and tuning of models for accurate simulation of CT spatial resolution using CatSim,” Physics in Medicine & Biology, 2024.
Planned / Possible:
MC-GPU: Future integrations may include wrappers for MC-GPU (used in VICTRE), allowing users to switch between ray-tracing (XCIST) and Monte Carlo (MC-GPU) backends within the same study definition.
Installation¶
For Users:
To install the latest stable version of VITools, you can install directly from the git repository:
pip install git+https://github.com/DIDSR/VITools.git
For Developers:
If you plan to contribute to VITools or want to install it in an editable mode, follow these steps:
# 1. Clone the repository
git clone https://github.com/DIDSR/VITools.git
cd VITools
# 2. Install in editable mode
pip install -e .
This will install the package and its dependencies, and any changes you make to the source code will be immediately effective.
Core Concepts¶
A virtual imaging trial is composed of three primary components:
a Phantom
a Scanner
a Study
Phantom¶
The Phantom class is a container for a numpy array and some metadata, like the patient’s age and the voxel spacings.
Scanner¶
A Scanner takes a Phantom and simulates a CT scan, generating projection data and a reconstructed image. It wraps the simulation backend (e.g., XCIST) and is configured with a specific Phantom.
Basic Usage¶
Here is a complete example of how to create a simple phantom, simulate a scan, and save the result as a DICOM file.
import numpy as np
from VITools import Phantom, Scanner
# 1. Create a simple phantom
# A 100x100x100 voxel phantom with a 50x50x50 high-density sphere inside.
print("Creating a phantom...")
image_shape = (100, 100, 100)
img = np.full(image_shape, -1000, dtype=np.int16) # Air
center = tuple(s // 2 for s in image_shape)
radius = 25
z, x, y = np.ogrid[-center[0]:image_shape[0]-center[0], -center[1]:image_shape[1]-center[1], -center[2]:image_shape[2]-center[2]]
mask = x*x + y*y + z*z <= radius*radius
img[mask] = 100 # Set sphere to a value like soft tissue
# Define voxel spacings in mm (z, x, y)
spacings = (0.5, 0.5, 0.5)
phantom = Phantom(img, spacings, patient_name="TestSphere", patientid=1)
# 2. Initialize the Scanner with the phantom
# This will prepare the phantom for simulation (voxelization).
print("Initializing the scanner...")
scanner = Scanner(phantom, scanner_model="Scanner_Default")
# 3. Run the scan and reconstruction
print("Running the simulation...")
scanner.run_scan(mA=200, kVp=120, views=100)
scanner.run_recon(fov=250, slice_thickness=1.0)
# 4. Save the output to DICOM
print("Writing output to DICOM files...")
output_dcm_path = "./output/dicom/test_sphere.dcm"
dcm_files = scanner.write_to_dicom(output_dcm_path)
print(f"Successfully created {len(dcm_files)} DICOM files in ./output/dicom/")
Interactive Examples¶
For more in-depth, runnable examples of each component, please refer to the following Jupyter notebooks:
Advanced Usage: The Study Class¶
For more complex experiments, the Study class can automate running hundreds or thousands of simulations. You can define a study plan in a CSV file or generate one programmatically.
from VITools import Study
# Generate a study plan with 5 different cases
study_plan = Study.generate_from_distributions(
phantoms=['MyCustomPhantom'], # Requires a registered custom phantom
study_count=5,
output_directory='my_large_study',
kVp=[100, 120],
mA=[150, 200, 250]
)
# Create a Study object and run all simulations
# This can run in parallel on a supported cluster (e.g., SGE)
study = Study(study_plan)
study.run_all(parallel=True)
Command Line Interface¶
VITools includes a command-line utility for running simulations. The generate command runs simulations defined in a CSV file.
For detailed usage, please refer to the documentation.
Extensibility: Creating Custom Phantoms¶
VITools uses a plugin architecture based on pluggy that allows you to create your own phantom generators and make them available to the Study class. To create a new phantom, you need to:
Create a new installable Python package.
In your package, create a class that inherits from VITools.Phantom.
Register your new phantom class using the register_phantom_types hook.
For a detailed example, please refer to one of the repositories using VITools.
Repositories using VITools¶
The following repositories demonstrate the phantom-agnostic nature of VITools, applying the same simulation orchestration to diverse anatomical regions:
InSilicoICH: For generating synthetic non-contrast CT datasets of intracranial hemorrhage (ICH).
PedSilicoLVO: For generating synthetic large vessel occlusion (LVO) non-contrast CT datasets.
PedSilicoAbdomen: For generating synthetic abdominal non-contrast CT datasets of liver metastases.
InSilicoGUI: Provides a graphical user interface to the phantoms and imaging simulations.
