Camera Stage Review Window

User could use this button to take image of the current camera review. If the user has chosen stage control system, the default image name has stage position information. Otherwise, the default name is in format "cam_+number". User could also edit the image name and saving directory.



User could choose the working system here. Without choosing a system "Stage current position" and "Stage destination position" will be disabled. But tge user could still use "Take image" button to get camera image



Get current stage positions and display them in part 4



When user clicks "Get position", "Move stage" or "Take image" buttons, current stage position will update to here



Move the stage to the position that user input in part 6. This button only enables when user inputs both X and Y position in part 6



Input the destination positions for stage



Exact view of the WSI image
